Green Pin grab hook

Green Pin® Grab Hook E EN 1677-1 - Image 2

Green Pin® Grab Hook E EN 1677-1

MATERIAL	Alloy steel, grade 8, quenched and tempered
SAFETY FACTOR	MBL equals 4 x WLL
STANDARD	EN 1677-1
FINISH	Painted white
TEMPERATURE RANGE	-40°c up to +200°c
CERTIFICATE	As standard; EC Declaration of Conformity Upon request; 2.1, 2.2, 3.1, MPIb, DGUV (*excluding sizes 20mm, 22mm, 26mm and 32mm)

Grab Hook E (CRO)

1 file(s) 166.38 KB

Download

Categories: Grade 8, Hooks

Description

Description

Working	For Chain	Length	Inside	Inside	Opening	Thickness	Width	Width	Length	Width	Thickness	Product	Weight
Load Limit	Diameter		Length	Width				Outside	Outside			Code	Each
		a	b	c	d	e	f	g	h	i	j
t	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm		kg
1.12	6	41	24	23	8	24	20	42	94	9	6	CRO6	0.25
2.0	7-8	53	27	26	10	33	23	53	115	10	8	CRO7/8	0.45
3.2	10	65	38	36	12	40	29	66	146	14	10	CRO10	0.91
5.4	13	83	42	41	15	56	40	88	183	16	12	CRO13	1.99
8.2	16	103	44	41	18	66	43	96	211	20	20	CRO16	2.49
12.8	20	130	37	37	22	75	48	128	241	26	26	CRO20	4.30
15.5	22	120	44	44	25	77	57	132	247	26	26	CRO22	8.50
21.6	26	158	46	46	30	100	82	177	320	32	32	CRO26	14.7
32.8	32	210	57	57	38	91	88	215	395	39	39	CRO32	18.0

×
