Green Pin® Catch Shackle
| MATERIAL | Bow and pin high tensile steel, Grade 6, quenched and tempered |
|---|---|
| SAFETY FACTOR | MBL equals 6 x WLL |
| STANDARD | EN 13889 and meets performance requirements of US Fed Spec. RR-C-271 Type IVA Class A and comply with ASME B30.26 |
| FINISH | Hot dipped galvanised |
| CERTIFICATION | As standard; Declaration of Conformity Upon request; 2.1, 2.2, 3.1, MTCa, CE |
| NOTE | Supplied without wires |
Description
| Working | Diameter | Diameter | Diameter | Width | Width | Length | Width | Length | Length | Width | Thickness | Diameter | Height | Width | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Load Limit | Bow | Pin | Eye | Eye | Inside | Inside | Bow | Bolt | Nut | Hole | Each | ||||
| a | b | c | d | e | f | g | h | i | j | k | l | m | n | ||
| t | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | kg |
| 2 | 13.5 | 16 | 34 | 13 | 22 | 51 | 32 | 89 | 102 | 58 | 19 | 15 | 48.4 | 27 | 0.47 |
| 3.25 | 16 | 19 | 40 | 16 | 27 | 64 | 43 | 110 | 122 | 75 | 23 | 15 | 53.7 | 31.8 | 0.81 |
| 4.75 | 19 | 22 | 46 | 19 | 31 | 76 | 51 | 129 | 143 | 89 | 26 | 15 | 60.1 | 36.5 | 1.32 |
| 6.5 | 22 | 25 | 52 | 22 | 36 | 83 | 58 | 144 | 160.5 | 102 | 29 | 15 | 65.5 | 41.3 | 1.92 |
| 8.5 | 25 | 28 | 59 | 25 | 43 | 95 | 68 | 164 | 183 | 118 | 32 | 15 | 70.5 | 46 | 2.77 |
| 9.5 | 28 | 32 | 66 | 28 | 47 | 108 | 75 | 185 | 201 | 131 | 34 | 15 | 74 | 50.8 | 3.91 |
