Green Pin® Round Web Sling Connector
| MATERIAL | Alloy steel, grade 8, quenched and tempered |
|---|---|
| SAFETY FACTOR | MBL equals 4 x WLL |
| FINISH | Painted white |
| TEMPERATURE RANGE | -40°c up to +200°c |
| CERTIFICATE | As standard; EC Declaration of Conformity Upon request; 2.1, 2.2, 3.1 |
Description
| Working | Width | Diameter | Width | Length | Width | Length | Thickness | Width | Product | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| Load Limit | Pin | Inside | Bow | Outside | Outside | Code | Each | |||
| a | b | c | d | e | f | g | h | |||
| t | mm | mm | mm | mm | mm | mm | mm | mm | kg | |
| 2.00 | 14 | 9 | 33 | 35 | 23 | 66 | 15 | 59 | CSO60 | 0.18 |
| 3.20 | 18 | 13 | 44 | 45 | 30 | 86 | 20 | 75 | COS90 | 0.37 |
| 5.40 | 22 | 16 | 57 | 59 | 38 | 107 | 25 | 94 | COS150 | 0.72 |
| 8.20 | 28 | 20 | 70 | 72 | 48 | 133 | 31 | 117 | COS240 | 1.35 |
