Green Pin® Omega Link EN 1677-1
| MATERIAL | Alloy steel, grade 8, quenched and tempered |
|---|---|
| SAFETY FACTOR | MBL equals 4 x WLL |
| STANDARD | EN 1677-1 |
| FINISH | Painted white |
| TEMPERATURE RANGE | -40°c up to +200°c |
| CERTIFICATE | As standard; EC Declaration of Conformity Upon request; 2.1, 2.2, 3.1 |
Description
| Working | For Chain | Width | Diameter | Width | Length | Width | Length | Thickness | Width | Width | Thickness | Product | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Load Limit | Diameter | Pin | Inside | Bow | Outside | Outside | Outside | Code | Each | ||||
| a | b | c | d | e | f | g | h | i | j | ||||
| t | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | kg | |
| 0.80 | 5 | 14 | 6 | 7 | 26 | 20 | 53 | 13 | 41 | 28 | 6 | CO5 | 0.07 |
| 1.12 | 6 | 14 | 8 | 7 | 25 | 20 | 53 | 13 | 41 | 28 | 6 | CO6 | 0.07 |
| 2.00 | 7-8 | 20 | 9 | 9 | 34 | 24 | 71 | 16 | 55 | 32 | 9 | CO7/8 | 0.20 |
| 3.20 | 10 | 19 | 13 | 12 | 40 | 31 | 82 | 17 | 63 | 42 | 11 | CO10 | 0.28 |
| 5.40 | 13 | 25 | 16 | 15 | 51 | 40 | 106 | 20 | 84 | 54 | 14 | CO13 | 0.64 |
| 8.20 | 16 | 32 | 20 | 19 | 64 | 48 | 132 | 25 | 104 | 68 | 17 | CO16 | 1.28 |
| 12.8 | 18-20 | 38 | 24 | 23 | 80 | 59 | 163 | 30 | 126 | 82 | 22 | CO18/20 | 2.25 |
