Bownut Metric Thread
Bownut Metric Thread
MATERIAL |
High tensile steel |
SAFETY FACTOR |
MBL equals 5 x SWL |
STANDARD |
Generally to BS3974 – Part 1 – 1974 |
FINISH |
Self colour or zinc plated |
CERTIFICATION |
As standard; EC Declaration of Conformity |
Description
Working | Diameter | Diameter | Diameter | Diameter | Base | Height | Product | Product | Weight |
Load Limit | Thread | Eye | Base | Inside | Height | Overall | Code | Code | Each |
| a | b | c | d | e | f | | | |
t | mm | mm | mm | mm | mm | mm | Self Colour | Zinc Plated | kg |
0.23 | 8 | 10 | 32 | 25 | 16 | 64 | 28001 | | 0.15 |
0.36 | 10 | 10 | 32 | 25 | 16 | 64 | 28002 | 28102 | 0.15 |
0.53 | 12 | 12 | 38 | 30 | 17 | 73 | 28003 | 28103 | 0.27 |
1.01 | 16 | 12 | 38 | 30 | 17 | 73 | 28004 | 28104 | 0.29 |
1.58 | 20 | 14 | 45 | 40 | 25 | 102 | 28005 | 28105 | 0.50 |
2.28 | 24 | 17 | 50 | 50 | 29 | 124 | 28006 | 28106 | 0.90 |
3.65 | 30 | 26 | 70 | 75 | 29 | 149 | 28007 | | 2.20 |
5.34 | 36 | 26 | 70 | 75 | 29 | 149 | 28008 | | 2.20 |
